Single-Column Mobile Aluminum Alloy Lifting Platform(Plug-Intype)

Single-Column Mobile Aluminum Alloy Lifting Platform(Plug-Intype)

Detail Description

Anti-misoperation button:
There are emergency stop, rise, fall and public buttons on the control board; When ascending or descending, keep pressing the corresponding button and the “Public” button simultaneously to start the ascending or descending. Avoid accidents caused by workers accidentally touching or by misoperation of single key start lifting.

Leg interlock: The platform can be lifted only after the four legs are installed in place and the landing force is applied.

Leg light: All four legs must be properly installed in place and on the ground, the four lights on the control panel will all light up, and the machine can be powered up and down. Resolutely put an end to safety accidents that occur because workers do not operate according to regulations or use machines without inserting legs.

Aluminum alloy leg: Adopt aluminum alloy inserting leg, larger contact area, more stable structure. The aluminum alloy legs are maintenance-free for life.

Synchronization device: Synchronization device can ensure that the equipment in the process of rising or falling, in the case of a slight obstruction inside the mast, each mast can rise or fall simultaneously

Signal line: high flexibility drag chain cable, bending life: 50 times/min, > 5 million times, shallow water, oil, UV resistance, weather resistance, cold resistance, wear resistance, can withstand heavy mechanical external force
